Phosphorescent Pigments
Lumilux� Effect Green N-F (50081)
Main use: Afterglow plastic sheets, screen printing inks, injection molding
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
Lumilux N-series products are phosphorescent pigments that store energy when exposed to the sun or an artificial light source, and emit light long after the source has been removed. They are zinc sulfide-based, and meet UL and CE safety standards.
Specifications
Others
- Application
- Ink
- Plastic
- Plastic
- CAS Number
- Not determined
- Compatibility
- Insoluble in water, alkalies, organic solvents and decomposed by acids
- Maximum Particle Size
- 38, PSD50
- Particle Texture/Size
- Coarse (D50 30 - 40 µm)
- Product Type
- Luminescent/Phosphorescent Pigments Millimeter-PRD
- Typical Uses
- Ceramics
- Enamel
- Solvent-based paints and inks
- Thermoplastics
- Thermosetting plastics
- Water-based paints
- Chemical Class
- No data available
- Brightness
- 2.7 after 60 minutes
- 27 after 10 minutes
- 64 after 5 minutes
- Chemical Composition
- ZnS: Cu
- Color
- Yellow-green
- Luminance DIN 67510-1
- 2.7 mcd/m2 after 60 minutes
- 27 mcd/m2 after 10 minutes
- 64 mcd/m2 after 5 minutes
- Particle Size Distribution
- < 38 μm, PSD50
- pH
- > 11 of a waterbased slurry
- Phosphorescence Color
- Green
- Physical Form
- Powder
- Screen Analysis
- < 0.5% oversized particles on 100 μm testing screen
- Solubility
- Insoluble
- Chemical Stability
- No data available
- Incompatible Materials
- Strong acids
Others
- Application
- Ink
- Plastic
- Plastic
- CAS Number
- Not determined
- Compatibility
- Insoluble in water, alkalies, organic solvents and decomposed by acids
- Maximum Particle Size
- 38, PSD50
- Particle Texture/Size
- Coarse (D50 30 - 40 µm)
- Product Type
- Luminescent/Phosphorescent Pigments Millimeter-PRD
- Typical Uses
- Ceramics
- Enamel
- Solvent-based paints and inks
- Thermoplastics
- Thermosetting plastics
- Water-based paints
- Chemical Class
- No data available
- Brightness
- 2.7 after 60 minutes
- 27 after 10 minutes
- 64 after 5 minutes
- Chemical Composition
- ZnS: Cu
- Color
- Yellow-green
- Luminance DIN 67510-1
- 2.7 mcd/m2 after 60 minutes
- 27 mcd/m2 after 10 minutes
- 64 mcd/m2 after 5 minutes
- Particle Size Distribution
- < 38 μm, PSD50
- pH
- > 11 of a waterbased slurry
- Phosphorescence Color
- Green
- Physical Form
- Powder
- Screen Analysis
- < 0.5% oversized particles on 100 μm testing screen
- Solubility
- Insoluble
- Chemical Stability
- No data available
- Incompatible Materials
- Strong acids
- Application : Ink|Plastic|Plastic
- Typical Uses : Ceramics|Enamel|Solvent-based paints and inks|Thermoplastics|Thermosetting plastics|Water-based paints
- Product Type : Luminescent/Phosphorescent Pigments Millimeter-PRD
- Particle Texture/Size : Coarse (D50 30 - 40 µm)
- Maximum Particle Size : 38, PSD50
- Compatibility : Insoluble in water, alkalies, organic solvents and decomposed by acids
- CAS Number : Not determined
- pH : > 11 of a waterbased slurry
- Solubility : Insoluble
- Screen Analysis : < 0.5% oversized particles on 100 μm testing screen
- Physical Form : Powder
- Phosphorescence Color : Green
- Particle Size Distribution : < 38 μm, PSD50
- Luminance DIN 67510-1 : 2.7 mcd/m2 after 60 minutes|27 mcd/m2 after 10 minutes|64 mcd/m2 after 5 minutes
- Color : Yellow-green
- Chemical Composition : ZnS: Cu
- Brightness : 2.7 after 60 minutes|27 after 10 minutes|64 after 5 minutes
- Incompatible Materials : Strong acids
- Chemical Stability : No data available
- Chemical Class : No data available
